Multi 9420 Transmitting data
ba75964e04 04/2015 109
11.5 Options for data transmission to the USB-B (PC)
interface and the USB-A (USB printer) interface
Via the USB-B interface you can transmit data to a PC.
Via the USB-A interface, you can transmit data to a USB printer or USB mem-
ory device. How to transmit data to a USB memory device is described in an
extra section (see section 11.6 D
ATA TRANSMISSION TO THE USB-A INTERFACE
(USB
MEMORY DEVICE), page 110).
The following table shows which data are transmitted to the interface in which
way:
Data Control Operation / description
Current
measured
values of all
connected
sensors
Manual With <PRT>.
Simultaneously with every manual data storage process (see
section 10.1 M
ANUAL DATA STORAGE, page 101).
Automatic, at
intervals
With <PRT_>.
Then you can set the transmission interval.
Simultaneously with every automatic data storage process (see
section 10.2 A
UTOMATIC DATA STORAGE AT INTERVALS, page 101).
Stored mea-
sured values
Manual Displayed dataset with <PRT> after calling up from the storage.
All datasets with the Output to RS232/USB function.
(see section 10.3.1 E
DITING THE MEASUREMENT DATA STORAGE,
page 104).
All datasets with the Output to USB flash drive or printer function
(USB-A interface)
For details, see section 10.3.1 E
DITING THE MEASUREMENT DATA
STORAGE, page 104.
Calibration
records
Manual Displayed calibration record with <PRT> (see section 4.2.6 C
ALI-
BRATION DATA, page 36; section 7.3.6 CALIBRATION DATA, page
75; section 8.3.4 C
ALIBRATION DATA, page 82).
All calibration records with the Output to USB flash drive or
printer function.
All calibration records with <PRT_>.
For details, see section 11 T
RANSMITTING DATA, page 107.
Automatic At the end of a calibration procedure.
The following rule applies: With the exception of the menus, shortly
pressing the <PRT> key generally outputs the display contents to
the interface (displayed measured values, measurement datasets,
calibration records).
