Multi 9420
ba75964e04 04/2015 21
Forgotten the
password?
Contact the administrator.
3.8 Navigation
3.8.1 Operating modes
3.8.2 Measured value display
In the measured value display, you can
use <><> to select one of several connected sensors. The selected
sensor is displayed with a colored background.
The following actions / menus refer to the selected sensor
open the menu for calibration and measurement settings with <ENTER>
(short
keystroke)
open the Storage & config menu with the sensor-independent settings by
pressing <ENTER_> (long
keystroke, approx. 2 s).
change the display in the selected measuring screen (e. g. pH <−> mV) by
pressing <M>.
3.8.3 Menus and dialogs
The menus for settings and dialogs in procedures contain further subelements.
5. In the Password field, enter the old password with <><> and
<><>and confirm it with <ENTER>.
6. In the New password field, enter the new password with <><> and
<><>and confirm it with <ENTER>.
The password is changed.
The login takes place. If a sensor is connected the measured value dis-
play appears.
Operating
mode
Explanation
Measuring The measurement data of the connected sensor are shown
in the measured value display
Calibration The course of a calibration with calibration information, func-
tions and settings is displayed
Storage in
memory
The meter stores measuring data automatically or manually
Transmittin
g data
The meter transmits measuring data and calibration records
to a USB interface automatically or manually.
Setting The system menu or a sensor menu with submenus, set-
tings and functions is displayed
