wtw Multi 9420 - ISE Measurement Settings

Multi 9420 Settings
ba75964e04 04/2015 89
Default settings are printed in bold.
9.3 ISE measurement settings
The settings are made in the measuring menu of the ISE measurement. To
open the settings, activate the relevant measuring window in the measured
value display and press the <ENTER> key shortly
. After completing the set-
tings, switch to the measured value display with <M>.
The following settings are possible for ISE measurements:
Menu item Possible setting Explanation
mV resolution 0.1
1
Resolution of the mV display
Reset - Resets all sensor settings to the
delivery condition (see section
9.7.1 R
ESETTING THE MEASUREMENT
SETTINGS, page 97).
Menu item Possible setting Description
Calibration /
Calibration record
- Displays the calibration
record of the last calibration.
Calibration /
Calibration data stor-
age /
Display
- Displays the calibration
record.
Further options:
 Scroll through the cali-
bration records with
<><>.
 Output the displayed cal-
ibration record to the
interface with <F2>/
[USB-Ausgabe].
 Output all calibration
records to the interface
with <F2_>[USB-Aus-
gabe].
 Quit the display with
<F1>/[Back] or
<ENTER>.
 Switch directly to the
measured value display
with <M>.
Calibration /
Calibration data stor-
age /
Output to RS232/
USB
- Outputs the calibration
records to the interface.
