Wulfsberg FLEXCOMM II C-5000 User Manual

C-5000 Pilot’s Guide
Publication No. 150-041103 Page 21 of 51
Rev. C C-5000 Pilot’s Guide
Nov 2013
Changing Receiver Bandwidth
The receiver bandwidth can only be changed on the manual channel. To change the manual channel’s
receiver bandwidth, do the following.
 Move the cursor under the bandwidth field, as depicted below.
. . M 5 0 6
.
9
8
7
R
T
.
1
7
F M
S H 5 0 9
.
9
8
7
T
T
.
1
7
. .
 Rotate the VALUE knob in either direction. Each turn of the VALUE knob will select the next
bandwidth option in the list. Turn the VALUE knob until the desired bandwidth symbol is displayed.
The available options are as follows.
N – Narrow – 12.5 kHz
S – Standard - 25 kHz
W – Wide – 35 kHz
X – Extra Wide – 70 kHz
Unless specifically instructed otherwise, always select “S” (Standard)..
