XAG AUSTRALIA
V40 Agricultural UAV
Model 3WWDZ-15.2AH
Flight Control System Super X 4
Symmetrical Motor Wheelbase 1600mm
Dimensions 1790 x 830 x 700mm
Empty Weight 29.8kg
Rated Takeoff Weight/Maximum Takeoff Weight 45.8kg/48kg
Protection Rating IP67
V40 Agricultural UAV
Operating Frequency 2.4000GHz-2.4835GHz
Maximum Thrust-Weight Ratio: 1.8
Hovering Precision (good GNSS signal)
RTK Enabled: ±10cm (horizontal), ±10cm (vertical)
RTK Disabled: ±0.6m (horizontal), ±0.3m (vertical)
(radar enabled: ±0.1m)
Continuous High Precision Navigation Time
without Signal
Hovering Duration
13.5min (with No-load @20000mAh & Takeoff
Weight: 29.8kg)
6.8min (with Full-load @20000mAh & Takeoff
Weight: 45.8kg)
Maximum Flying Speed 7m/s
Maximum Flying Height 30m
Maximum Flight Distance 2000m
Wind Force Recommended
Flight Parameters
