01
LED – Battery Level Indicates the Battery Level of the Remote Controller
02
LED – Smart Device Status Indicates whether the remote controller is connected to Smart Device
03
LED – Device Status Indicates whether the remote controller is linked to the Aircraft
04
LED – Control Mode Indicates the Flight mode of the Device (Manual / Autonomous)
05
LED – Terminal Status Indicates whether the remote controller is connected to Terminal
06
LED – RTK Status Indicates the RTK Status of the Remote Controller
07
Heat Sink Used to dissipate heat from internal Components
08
Spray/Spread + Increase the rate of Spray / Spread
09
Spray / Spread Button Press to Enable / Disable Spray or Spread
10
Spray/Spread – Decrease the rate of Spray / Spread
11
Speed + Increase Speed
12
Speed Broadcast Button Press to broadcast the current Speed
13
Speed – Decrease Speed
14
Button A Mapping Mode: Add Point
15
Smart Mode Button Long Press to Enter / Exit mapping Mode
16
Button B Mapping Mode: Undo previous Added Point
17
Yaw Control – Left
Rotate Device CCW (Counter-Clockwise)
18
Yaw Control – Right Rotate Device CW (Clockwise)
19
Terrain Button Used to Broadcast and Turn ON/OFF Terrain Following
20
RTH Button Press and Hold this RTH button to initiate Return to Home (RTH)
21
Directional Control – Forward
22
Directional Control – Sideway Right
23
Directional Control – Backward
24
Directional Control – Sideway Left
25
Hover Button Press to Hover or Long Press to resume Autonomous Operation
26
Power Button Used to turn ON/OFF the remote controller
27
Nano SIM Slot Provides Cellular connection
28
Altitude + Increase Altitude
29
Altitude – Decrease Altitude
30
Power Port Connects to a power source to charge the Remote Controller
