Xantrex Freedom XC 2000 User Manual

Troubleshooting Reference
975-0784-01-01 79
Problem Possible Cause Solution
No output voltage. The status LED is
not lighting up.
Ignition lock (ACC) signal is not
present.
If the ignition control feature is in use, ensure the
vehicle’s ignition is On and the ignition control switch on
the front of the Freedom XC unit is On (|).
The fan turns on and off during AC
shore power mode.
The battery is discharged.
AC pass-through current is high.
Do not be alarmed, the unit is performing normally.
The fan turns on and off during inverter
mode.
The inverter is running
continuously at high power.
Do not be alarmed, the unit is performing normally. The
fan is activated automatically.

Xantrex Freedom XC 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Waveform	Pure Sine Wave
Efficiency	90%
Operating Temperature	-4°F to 140°F (-20°C to 60°C)
Transfer Time	20ms
