Xerox 700 - Replacing the Waste Toner Container

Xerox 700 Digital Color Press User Guide 7-21
Maintenance
12. Return the R1-R4 handle to the original
position and close the front door.
11. Push in the Drum Drawer completely.
Return the Release Handle to its original
position.
13. Insert the used charge corotron into an
empty container for recycling.
That completes the procedure for replacing the
Charge Corotron.
10. Grasp the amber-gold colored casings on
the new charge corotron and pull towards the
front of the machine until you hear a clicking
noise to indicate the charge corotron is in
place.
This procedure shows you how to remove the
used Waste Toner Container and replace it
with a new Waste Toner Container. The
machine will tell you when you need to order a
new Container and when to install it.
Replacing the Waste Toner Container
1. Make sure the machine has stopped
running, and open the Front Door.
2. Open the waste toner container cover,
located to the right of the Area #2 lever.
