Xerox 700 Digital Color Press User Guide3-8
Paper
The Bypass Tray is a paper tray on the left
hand side of your machine. It can be folded
away when not in use.
It is primarily intended for use as a small
quantity, special materials feeder and
accommodates stock of all types.
The Bypass Tray accommodates all types
of stock in a range of sizes between
4.0"x6.0" and 13"x19" and has a capacity
of approximately 250 sheets of 20lb paper
or a maximum stack height of 0.4".
Hole punched paper should be loaded with
the holes on the leading (right) edge.
Tabbed stock should be loaded with the
tabs on the trailing (left) edge.
The tray accommodates paper of weights
between 17lb bond to 300gsm.
Stock can be loaded either long or short
edge feed (portrait or landscape).
NOTE: The Bypass Tray is only 13" wide,
so some paper sizes must be SEF.
When lowered, the Bypass Tray can be
extended to support longer length stock.
Bypass Tray (Tray 5)
