Xerox 700 - Loading the Oversized High Capacity Feeder

Xerox 700 Digital Color Press User Guide 3-15
Paper
The Oversized High Capacity Feeder can hold up
to 2000 sheets of 60-300 gsm 13" x 19"/SRA3
paper.
This procedure shows you how to load paper into
the Oversized High Capacity Feeder.
After opening the tray, register the stack of paper
or media against the front right side of the paper
tray. The paper or media must not be loaded
above the maximum fill line.
Move the paper guides to just touch the edges of
the stack.
Loading the Oversized High Capacity Feeder
Move both Paper Weight Switches to their
appropriate positions.
CAUTION:
For paper heavier than 256 g/m2, slide both
Paper Weight Switches to the heavier weight
position (257 g/m2 - 300 g/m2). Failure to do
so may result in paper jams.
Push in the tray gently until it comes to a stop.
When the loaded tray is closed, the tray position is
automatically adjusted in the front/back direction
based on the paper size.
