9. Return the green lever A1 to its locked position.
10. If the paper is jammed at the exit to the center output tray, pull the paper in the direction shown.
Note: Toner can adhere to the transfer roller. The toner that does adhere to the transfer roller does not
affect print quality.
11. Close Door A, then close Tray 5.
264 Xerox
®
EC8036/EC8056 Color Multifunction Printer User Guide
Troubleshooting
