PPaappeerr TTrraayy OOppttiioonnss
Configuring Dedicated Paper Trays
The system administrator can set trays to Fully Adjustable mode or Dedicated mode. When a paper
tray is set to Fully Adjustable mode, you can change paper settings each time that you load the tray.
When a paper tray is set to Dedicated mode, the control panel prompts you to load a specific paper
size, type, and color.
Your printer can have three high-capacity paper trays installed, depending on the configuration.
• High-Capacity Trays are configured as Dedicated trays.
• Trays 3 and 4 in the Tandem Module, and High Capacity Tray 6 hold A4-size (210 x 297 mm),
Letter-size (8.5 x 11 in.), JIS B5-size (182 x 257 mm), or Executive-size (7.25 x 10.5 in.) paper.
• High-Capacity Trays are designed to hold larger amounts of paper for fewer printing interruptions.
Note: To configure tray settings, refer to the System Administrator Guide at www.support.xerox.
com.
Configuring Trays 3 and 4 of the Tandem Tray Module
Trays 3 and 4 in the Tandem Tray Module are high-capacity paper trays. Configure Trays 3 and 4 to
support the paper in use.
If you are configuring the trays for the first time, configure them for the paper size that you need. If
you change the paper size, reconfigure the tray for the new paper size. For details on supported paper
sizes, refer to Supported Standard Paper Sizes.
To configure Trays 3 and 4 in the Tandem Tray Module:
Note: Before you make any tray adjustments, compare the paper size to the current Tray 3 and
4 configurations. If the paper size matches the tray configuration, no tray adjustment is
needed.
1. Remove any paper from the tray.
2. Pinch the guide lock on the front paper guide, then slide the paper guide to the required paper
size.
3. To lock the paper guides into place, release the guide lock.
Note: The paper guides lock into place only at the designated standard paper sizes.
Configuring Tray 6
Tray 6 is a dedicated High-Capacity Tray. You can configure Tray 6 to support the paper size that you
need. For details on supported paper sizes, refer to Supported Standard Paper Sizes.
To configure Tray 6:
Note: Before you make any tray adjustments, compare the paper size to the current Tray 6
configuration. If the paper size matches the tray configuration, no tray adjustment is needed.
34
Xerox
®
EC8036/EC8056 Color Multifunction Printer
User Guide
Getting Started
