General Procedures / Information
6-26 12/04 FaxCentre F110
Table 2: Other Functions
ITEM ACTION
* Internal system status printing (identification + T30 protocol traces + modem traces)
Menu * 1 Parameters printing (user parameters + technical parameters)
Menu * 2 Clear communication logs
Menu * 3 Not used
Menu * 4 Wait for firmware download via USB
Menu * 5 Save users parameters and directory on I2C chip card
Menu * 6 Not used
Menu * 7 Not used
Menu * 8 Not used
Menu * 9 Restore users parameters and directory from I2C chip card
Menu * E
Menu * e
Display internal firmware status (applications and drivers)
Menu * M
Menu * m
Display modem chip type
Menu * R
Menu * r
Software reset
Menu * V
Menu * v
Display firmware version and checksum on LCD
Menu * W
Menu * w
White Reference
Menu * Y
Menu * y
- If consumer counter value is higher than near end (6%), set counter value to 6%.
- If consumer counter value is lower than near end (6%), set counter value to 1%
