General Procedures / Information
FaxCentre F110 12/04 6-27
GP 10 Test Function
The test mode is a software interface that listen for test commands received on Fax Keypad. The
machine interprets these codes and initialize the corresponding action.
Go to :
• Enter Test Mode
• Display
• Keys used on Fax Keypad in Test Mode
• Abort Test
• Description of Test for Service
Enter Test Mode
First you have to set the FaxCentre F110 into maintenance mode.
(SOS1-Bit8 has to be set to one)
To enter in the Test Mode press the Key combination below on the keypad:
Menu # * 0
You will enter into the Test Mode and the following messages will appear on the displays:
ATTENTION: After you have entered in the Test Mode the first Test you have to carry out, is the
Test 100 Param. 00 (INIT Test Mode).
Display
The content of the display has following format:
YYY ... Shows Running Test or last test
XX ... Shows Result of last test
Keys used on Fax Keypad in Test Mode
• START Test Ok or Test start
• STOP Test failed or Test abort
• KEY 0-9, * ,# Input Test number
M O D EST E
T
M O D ESE
T
YYY XX
T
