Wiring Diagrams
7-6 12/04 FaxCentre F110
WD 4 Connector to LSU (P351)
Refer to WD 6 and GP 21
Table 1:
Name Pin I/O Active Current Function
CLK 1 O 2mA Clock for the motor
*READY 2 I Low 2mA Motor rotation detection
(Low=synchronised)
*START 3 O Low 2mA Motor rotation (Low=Start ;
High=Stop)
GND 4 Ground (Earth)
+24V 5 Power supply
NC 6 Not connected
GND 7 Ground (Earth)
Video* 8 O Low Video signal
LDEN* 9 O Low LED enable
-S/H* 10 O Low Enable LED power control
+5V 11 Power supply
GND 12 Ground (Earth)
GND 13 Ground (Earth)
*HSYNC 14 I Low 2mA Horizontal synchronisation
To Next Page
