Wiring Diagrams
FaxCentre F110 12/04 7-7
WD 5 Connector to OPU (P402)
Refer to GP 22 and WD 6
Table 1:
OPU I/O Level P400 Digicolor2 I/O DC2 function
P5V 1 Power supply 3.3V
GND 2 Ground (Earth)
CS_LCD* O 1 3 PP_nACK 156 LCD chip select
CS_PAN* O 1 4 PP_nSTROBE 167 Keypad chip select
TX_PAN O 5 USART0_TX 1 Serial link TX
RX_PAN I 6 USART0_RX 2 Serial link RX
GND 7 Ground (Earth)
SCLK_PAN O 8 USART0_CK 8 Serial link clock
DDS I 9 GP_A2 28 Document sensor (ADF)
DPS I 10 PI_TGEN0 131 Document position
sensor(ADF)
P3.3VOPU 11
