Xerox FaxCentre F110 Service Manual

Wiring Diagrams
FaxCentre F110 12/04 7-3
WD 1 Connector to PSU (P350)
Refer to GP 26 and WD 6.
Table 1:
Pin Signal Pin Signal
1 +24V after switch 2 +24V after switch
3 PRBEN* 4 TRREAD
5 TRPWM 6 RTRBEN*
7 DEBEN* 8 PAPER*
9 REGIST* 10 PICKUP*
11 +24V 12 +24V
13 GND 14 GND
15 GND 16 GND
17 +5V 18 +5V
19 +5V 20 +5V
21 -12V 22 HEAT
23 FAN* 24 PMOTB0*
25 PMOTA0 26 PMOTA0*
27 PMOTB0 28 SMOTB0*
29 SMOTB0 30 SMOTA0*
31 EXIT* 32 SMOTA0
