Repairs/Adjustments

4-14 12/04 FaxCentre F110

REP 8 Fuser Unit Removal

Parts List on PL 5

1. Perform REP 7.

2. Remove 2 screws.

Figure 1

3. Carefully lift the Fuser from the backside to release the hinge at the front.
