Xerox FaxCentre F110 Service Manual

Repairs/Adjustments
FaxCentre F110 12/04 4-3
REP 1 Disassembly Procedure Chart
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Tools
• Phillips screwdriver
• Flat screwdriver (medium size)
• Torx No. 9.
• Torx No. 20.
1. Remove the document trays and the paper cassette.
Main Cover
Upper Guide Assembly
Operation Panel
(REP 5)
(REP 3)
(REP 6)
(REP 4)
(REP 2)
Main Controller
PWB
Repairs
Drive Module
(REP 9)
Scanner CIS ROS
Fuser Unit
(REP 8)
(REP 7)
Paper Feeder and Feed
Roll Assembly
Transfer Roll
Power Supply Unit
(REP 10)
