General Procedures / Information
6-28 12/04 FaxCentre F110
Abort Test
Use the STOP key to abort all tests.
General Description of a Test-Step
All test flows are described in the form outlined. The field Step is for orientation in case of Jumps,
Status is for decisions, Operator describes the actions of the Operator, UUT describes the actions
for the FaxCentre F110, Display shows the Text during a Test, and Remarks is for added Infor-
mation.
A short Test-description and Pass-criteria is also included in a Test-step.
Short Overview of Tests for Service
Table 1:
Step Status Operator UUT Display Remarks
1 OK Wait XXXXXXXX
XXXXXXXX
2 NOK Do Info
3 Repeat Do
4
Table 2:
Test number Test name Parameter Remark
100 INIT Test mode YES Save Consumer counter
103 Cradle No
108 Speaker No
109 Keys No
110 LCD/Icons No
111 LED No
112 Sensors No
120 Fan Test No
136 End Test mode No End test, restore Consumer counter,
delete doc’s, start USERMODE
