Service Call Procedures
1-4 12/04 FaxCentre F110
SCP 2 Final Actions
After the machine has been re-assembled, perform the steps that follow:
1. Perform the High Voltage Test, GP 47.
2. Perform any firmware upgrade, GP 11.
3. If a new main board has been installed, perform the Customization Update, GP 12.
4. If the memory has been erased use a new Plug and Print card to update the Consumable
Counter.
5. Clean the CIS and the CIS guide, PL 2, using a micro fibre wiper and lens and mirror cleaner,
PL 12.
6. Put the machine into Maintenance Mode GP 9 and set the white reference, (Menu, *W).
7. Perform the Margin Adjustment TBD.
8. Make copies in standard and photo mode.
9. Send and receive a Fax
10. Units with a handset only. Make and receive a call.
