DefinitionSymbol

Right Direction Indicator

Up Direction Indicator

Down Direction Indicator

Maximum Fill Line

Do not load media in the tray above this line.

Staple

Large Media Size Indicator

This shows the user where to position the tray lever for large media sizes.

Position Arrows

Clean Glass as Indicated

Toner

Empty Toner

Full Toner

Do Not Use Non-MICR (White)

Xerox

Nuvera

2-4

User Guide and Training Aid (UGTA)

Product Symbols
