Xerox WorkCentre 3025BI Service Manual

June 2014
2-11
Xerox® WorkCentre® 3025 Multifunction Printer Service Manual
10-100 , 10-200/ 300
Status Indicator RAPs
Check the voltage to the Over Heat Thermostat. The voltage is present..
YN
• Check for AC line voltage to the LVPS/HVPS PWB,
• Check that the connectors are tight and no contamination is present.
• Check the wire harness from the LVPS/HVPS PWB for a open or short circuit.
• Replace the LVPS/HVPS PWB (REP 1.6), PL 5.1.
Check the circuits and connectors for the Fuser Module.
Check the Heat Lamp for an open circuit.
Replace the Fuser Assembly (REP 1.19), PL 5.2.
10-200/ 300 Fuser Under/ Over Temperature Fault
10-200: The temperature of the Fuser is below of the normal operating range of 383°F ± 5°F
(195°C ± 5°C.)
10-300: The temperature of the Fuser is above the normal operating range of 383°F ± 5°F
(195°C ± 5°C.)
BSD-Reference: 10.1 Fuser
Initial Actions
Switch Off the power. Remove and reinstall the Fuser Assembly. Switch On the power.
Procedure
WARNING
Do not handle the fuser components until they have cooled. Some fuser components
operate at hot temperatures and can produce serious personal injury if touched.
DANGER: Ne pas manipuler les éléments du four avant de les laisser refroidir. Certains
éléments du four fonctionnent à des températures très élevées et peuvent causer de
graves blessures s'ils sont touchés.
AVVERTENZA: Non maneggiare i componenti del fusore finché non sono raffreddati.
Alcuni di questi componenti funzionano ad alte temperature e possono provocare gravi
ferite se vengono toccati.
VORSICHT: Die Fixieranlage sollte erst gehandhabt werden, wenn diese genügend
abgekühlt ist. Einige Teile der Fixieranlage erzeugen übermäßige Hitze und führen bei
der Berührung zu schweren Verbrennungen.
AVISO: No manipule los componentes del fusor antes de que se enfríen. Algunos de los
componentes del fusor funcionan a altas temperaturas y pueden ocasionar daños per-
sonales graves si se los toca.
Enter Diagnostic (EDC) Mode. Select: [DC330 Component Control, 109 Fuser Heat, Temp
A] to obtain a temperature reading from the Fuser. The Fuser temperature is within normal
operating range.
YN
Replace the Fuser Assembly (REP 1.19), PL 5.2.
If problem is intermittent, check the circuit of the Fuser Assembly for one of the following
• All connectors are securely connected and no contamination is present.
• Short circuit or damaged wire. Repair as necessary.
A

Xerox WorkCentre 3025BI Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Memory	128 MB
Duplex Printing	Manual
First Page Out	As fast as 8.5 seconds
Paper Input Capacity	150 sheets
Paper Output Capacity	100 sheets
Paper Capacity	150 sheets
Processor Speed	600 MHz
Dimensions	406 x 360 x 257 mm
Weight	7.5 kg
Scan Resolution	600 x 600 dpi
Maximum Document Size	216 x 356 mm
Connectivity	USB, Wi-Fi
Print Resolution	Up to 1200 x 1200 dpi enhanced image quality
Duty Cycle	Up to 15, 000 pages
