Rear View
Interface Ports
Front
USB Port
This port is provided for connection to a USB flash drive and is used as an input port for printing jobs,
storing jobs and performing a software upgrade.
Rear
Network Port
This port is used to connect the machine to the network.
Network Port Rear Door
Power Switch Paper Tray Rear Cover
Power Receptacles Telephone Line Socket
Duplex Unit Extension Telephone Socket
