PMU GPO (MIO 32-37)
The plaorm management unit (PMU) within the Zynq UltraScale+ RFSoC signals power domain
changes using the PMU output pins for deep-sleep mode. The Zynq UltraScale+ RFSoC PMU
GPO pins are connected to inputs of the MSP430 system controller through the TXS0108E level-
shier U37. The RFSoC U1 Bank 501 and MSP430 U38 pin numbers are listed in the following
table.
Table 14: XCZU48DR to MSP430 Connections
XCZU48DR (U1) Pin Net Name
MSP430 U38
Pin Name Pin Number
E32 MIO37_PMU_GPO5 P1_0 13
E31 MIO36_PMU_GPO4 P1_1 14
C33 MIO35_PMU_GPO3 P1_2 15
D31 MIO34_PMU_GPO2 P1_3 16
D32 MIO33_PMU_GPO1 P1_4 17
D34 MIO32_PMU_GPO0 P1_5 18
Through the I2C0 bus U1 PS-side MIO[14:15] pins, the PMU has access to the board power
controller PMBus bus (IRPS5401_SDA/SCL) and power monitor PMbus ( INA226_PMBUS_SDA/
SCL). See Figure 7 for addional details.
See the Zynq UltraScale+ Device Technical Reference Manual (UG1085) for details about the PMU
interface.
The detailed RFSoC connecons for the feature described in this secon are documented in the
ZCU208 board XDC le, referenced in Appendix B: Xilinx Design Constraints.
SDIO (MIO 39-51)
A PS-side interface to an SD card connector is provided for boong and le system storage. This
interface is used for the SD boot mode and supports SD3.0 access post boot.
SD Card Interface
[Figure 2, callout 7]
The ZCU208 board includes a secure digital input/output (SDIO) interface to provide access to
general purpose non-volale SDIO memory cards and peripherals. Informaon for the SD I/O
card specicaon can be found on the SanDisk Corporaon or SD Associaon websites. The
ZCU208 SD card interface supports the SD1_LS conguraon boot mode documented in the
Zynq UltraScale+ Device Technical Reference Manual (UG1085).
