Xinje DS5C Series User Manual

99
short circuit
circuit when
self-checking
2、 load blocked
UVW wiring
2. change drive
3. change motor
4. suggest to run
without load, to
troubleshoot
load problem
12
0
E-120
Current sensor
error
Current sensor
damaged or external
interference too large
Check the
ground wiring or
contact us
1
E-121
U phase current
sampling zero
calibration value
error
Current sensor
damaged or external
interference too large
Check the
ground wiring or
contact us
2
E-122
V phase current
sampling zero
calibration value
error
Current sensor
damaged or external
interference too large
Check the
ground wiring or
contact us
13
0
E-130
AB or UVW
phase of motor
orthogonal
encoder break
AB or UVW phase
break during
self-inspection
1. check encoder
cable wiring, use
multi-meter to
measure the
connection
2. change motor
14
2
E-142
Z-phase of
motor encoder
break
Z-phase break during
self-inspection
Disconnect the
power supply of
the driver to
check whether
the line is
connected
