Xinje DS5C Series User Manual

76
0
.xxx□
Pass Z phase signal times
after leaving the limit
switch
-
2
1~F
○
5、6
0.
xx□x
Find origin function
0: OFF 1: ON
-
0
0~1
○
5、6
01
Hit proximity switch
speed
1rpm
600
0~50000
○
5、6
02
Leaving proximity switch
speed
1rpm
100
0~50000
○
5、6
03
Internal position mode
-
n.0000
○
5
04
Effective segment number
1
1-35
○
5
10
First segment pulse (low
byte)
1 pulse
0
-9999~99
99
○
5
11
First segment pulse (high
byte)
10000
pulses
0
-32767~3
2767
○
5
12
First segment speed
0.1rpm
0
0~10000
○
5
13
First segment acceleration
time
1ms
0
0~65535
○
5
14
First segment deceleration
time
1ms
0
0~65535
○
5
15
Reserved
-
-
-
-
5
16
Adjustment time
1ms
0
0~65535
○
5
P4-17~P4-23 are internal position segment 2 parameters, the following total 35 segments.
Note: (1) setting pulse number = pulse numbers (high byte)×10000+pulse number(low byte)
(2) total 35 segments. Segment 1~12 parameters can be set through operate panel, segment
13~35 can write in parameters through communication (RS232 or RS485).
