7 Product Information
7.1 Specifications
Table 7-1: XCC detector specifications
Model XCC-010
Supply Voltage 18 to 30 VDC
Power Consumption 5.4 W quiescent, 5.9 W with alarm
Current Consumption 225 mA at 24 VDC normal operation, 245 mA with alarm
Fuse Rating 1.6A
Dimensions (WHD) 225 mm x 225 mm x 85 mm (8 7/8 in x 8 7/8 in x 3 3/8 in)
Weight 1.9kg (4.2 lbs)
Operating Conditions
XCC-010
Tested to -10°C to 55°C (14°F to 131°F)
Recommended Detector Ambient: 0° to 39° C (2° F to 103° F)
Sampled Air: -20° to 60° C (-4° to 140° F)
Humidity: 10-95% RH, non-condensing
Operating Conditions
XCC-01000-MRN
Tested to -25°C to 70°C (-13°F to 158°F)
Recommended Detector Ambient: 0° to 39° C (2° F to 103° F)
Sampled Air: -20° to 60° C (-4° to 140° F)
Humidity: 10-95% RH, non-condensing
Sampling Pipe Network Maximum Area of Coverage: 800m² (8000 sq. ft.)
Maximum Single Pipe Length: 80m (max. 12 holes)
Maximum Branched (2) Pipe Lengths: 50m each (max. 6 holes)
Pipe Design: Pre-engineered Pipe Networks (refer to page 6)
Pipe Size ID: 15-21 mm (0.874 in)
OD: 25 mm (1.050 in.)
Relays 3 relays, contacts rated 2A @ 30 VDC
l Fire-Alarm (NO)
l Pre-Alarm (NO)
l Fault (Maintenance and disable) (NC/NO)
Configurable as latching or non-latching
IP Rating IP30
Cable Access 4 x 25 mm (1 in.) cable entries
Cable Termination Screw terminal blocks (0.2-2.5 sq mm, 30-12 AWG)
Threshold Setting Range Refer to Pipe Networks on page 5.
