Relay outputs
Programmable relay outputs 2
Relay 01 terminal number 13 (break), 12 (make)
Maximum terminal load (AC-1)
1)
on 12 (NO) (resistive
load)
2)3)
400 V AC, 2 A
Maximum terminal load (AC-15)
1)
on 1–2 (NO) (inductive
load @ cosϕ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on 12 (NO) (resistive
load)
80 V DC, 2 A
Maximum terminal load (DC-13)
1)
on 1–2 (NO) (inductive
load)
24 V DC, 0.1 A
Maximum terminal load (AC-1)
1)
on 13 (NC) (resistive
load)
240 V AC, 2 A
Maximum terminal load (AC-15)
1)
on 1–3 (NC) (inductive
load @ cosϕ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on 13 (NC) (resistive
load)
50 V DC, 2 A
Maximum terminal load (DC-13)
1)
on 1–3 (NC) (inductive
load)
24 V DC, 0.1 A
Minimum terminal load on 1–3 (NC), 1–2 (NO) 24 V DC 10 mA, 24 V AC 2 mA
Environment according to EN 60664–1 overvoltage category III/pollution degree 2
Relay 02 (only) terminal number 4–6 (break), 4–5 (make)
Maximum terminal load (AC-1)
1)
on 45 (NO) (resistive
load)
400 V AC, 2 A
Maximum terminal load (AC-15)
1)
on 45 (NO) (inductive
load @ cosϕ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on 45 (NO) (resistive
load)
80 V DC, 2 A
Maximum terminal load (DC-13)
1)
on 45 (NO) (inductive
load)
24 V DC, 0.1 A
Maximum terminal load (AC-1)
1)
on 46 (NC) (resistive
load)
240 V AC, 2 A
Maximum terminal load (AC-15)
1)
on 46 (NC) (inductive
load @ cosϕ 0.4)
240 V AC, 0.2 A
Maximum terminal load (DC-1)
1)
on 46 (NC) (resistive
load)
50 V DC, 2 A
Maximum terminal load (DC-13)
1)
on 46 (NC) (inductive
load)
24 V DC, 0.1 A
Minimum terminal load on 46 (NC), 45 (NO) 24 V DC 10 mA, 24 V AC 20 mA
Environment according to EN 60664–1 overvoltage category III/pollution degree 2
1)
IEC 60947 part 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced
isolation (PELV).
2)
Overvoltage category II
3)
UL applications 300 V AC 2A
Control card, 10 V DC output
Terminal number 50
Output voltage 10.5 V ±0.5 V
Maximum load 15 mA
9 Technical Specification
