The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-
voltage terminals.
Control characteristics
Resolution of output frequency at 0–1000 Hz ± 0.003 Hz
System response time (terminals 18, 19, 27, 29, 32, 33) ≤ 2 ms
Speed control range (open loop) 1:100 of synchronous speed
Speed accuracy (open loop) 30–4000 rpm: maximum error ±8 rpm
All control characteristics are based on a 4–pole asynchronous motor
Surroundings
Enclosure type D1h/D2h/D5h/D7h/E1/E2 IP21/Type 1, IP54/Type 12
Enclosure type D3h/D4h IP20/Chassis
Enclosure type D1h and D2h 3R
Vibration test all enclosure types 1.0 g
Relative humidity 5% – 95% (IEC 72133; Class 3K3 (non-condensing)
during operation
Aggressive environment (IEC 60068243) H
2
S test class Kd
Test method according to IEC 60068–2–43 H
2
S (10 days)
Ambient temperature (at 60 AVM switching mode)
- with derating maximum 131°F (55°C)
1)
- full output power of typical EFF2 motors (up to 90%
output current)
maximum 122°F (50°C)
1)
- at full continuous FC output current maximum 113°F (45°C)
1)
Minimum ambient temperature during full-scale
operation
32°F (0°C)
Minimum ambient temperature at reduced performance 14°F (10°C)
Temperature during storage/transport 13°–149°/158°F (25 to +65°/70°C)
Maximum altitude above sea level without derating 3300 ft (1000 m)
Maximum altitude above sea level with derating 10,000 ft (3,000 m)
EMC standards, Emission EN 61800–3, EN 61000–6–3/4, EN 55011, IEC 61800–3
EMC standards, immunity EN 61800–3, EN 61000–6–1/2, EN 61000–4–2, EN
61000–4–3, EN 61000–4–4, EN 61000–4–5, EN 61000–
4–6
Derating for high altitude, see the Technical Bulletin for detailed information.
1)
For more information on derating see the Design Guide, section on Special Conditions.
Control card performance
Scan interval 5 ms
Control card, USB serial communication
USB standard 1.1 (full speed)
USB plug USB type B “device” plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other
high-voltage terminals.
The USB ground connection is not galvanically isolated from protection earth. Use only an
isolated laptop as PC connection to the USB connector on the frequency converter.
