Yamaha 2010 YZF-R6 User Manual

– 6 –
4. Piston Set (13S-116A0-70)
Select four pistons so that the difference in their weights does not exceed 0.5g.
5. Connecting Rod Set (13S-1165B-70)
Select four connecting rod assemblies so that the difference in their weights does not exceed
2g and combine them so that the small end weights are uniform.
(by Yamaha’s measuring method)
6. Crankshaft (2C0-11411-70)
Select a crankshaft with good balance.
Parts List
No. PART No. PART NAME Q'TY REMARKS
* 1 13S-11631-00 PISTON 4
* 2 2C0-11603-00 PISTON RING SET 4
* 3 2C0-11633-00 PIN, PISTON 4
* 4 93450-16159 CIRCLIP 8
Parts List
No. PART No. PART NAME Q'TY REMARKS
* 1 13S-11650-00 CONN. ROD ASSY., 1 4
Parts List
No. PART No. PART NAME Q'TY REMARKS
* 1 2C0-11411-00 CRANKSHAFT 1

Yamaha 2010 YZF-R6 Specifications

General

Bore x Stroke	67.0mm x 42.5mm
Compression Ratio	13.1:1
Fuel Delivery	Fuel Injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Final Drive	Chain
Rear Brakes	220mm disc; single-piston caliper
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Length	80.3 in
Width	27.8 in
Height	43.1 in
Seat Height	33.5 in
Wheelbase	54.1 in
Fuel Capacity	4.5 gal
Wet Weight	417 lb
Engine Type	Liquid-cooled, inline 4-cylinder, DOHC, 16 valves
Transmission	6-speed
Front Suspension	41 mm inverted fork; 4.7-in travel
Rear Suspension	Single shock; 4.7-in travel
Front Brakes	Dual 310mm disc; radial-mount 4-piston calipers
