– 2 –

2 Kit Parts

2-1 Engine Parts

1. Maintenance Set (2C0-MAINT-71)

Parts List

No. PART No. PART NAME Q'TY REMARKS

° 1 2C0-11181-76 GASKET, CYLINDER HEAD 3 t=0.45mm

* 2 2C0-11603-00 PISTON RING SET 12

* 3 93450-16159 CIRCLIP 24

4 2C0-1165A-00 BOLT, CONNECTING ROD 24

* 5 90179-07001 NUT 24

* 6 4SV-12119-00 SEAL, VALVE STEM OIL 48

* 7 2C0-12213-00 GASKET, TENSIONER 3

° 8 2C0-13414-70 GASKET, STRAINER 3 ANTI STICK TYPE

° 9 2C0-15451-70 GASKET, CRANKCASE

COVER 1

3 ANTI STICK TYPE

° 10 2C0-15461-70 GASKET, CRANKCASE

COVER 2

3 ANTI STICK TYPE

° 11 2C0-15456-70 GSKT., 1 3 ANTI STICK TYPE

* 12 93102-35017 SEAL, OIL 3 FOR DRIVE AXLE

* 13 90151-06024 SCREW,

CROSSRECESSED

COUNTERSUNK

9 FOR BEARING

HOUSING

Questions and Answers:

Need help?

Do you have a question about the Yamaha 2010 YZF-R6 and is the answer not in the manual?

General

Bore x Stroke	67.0mm x 42.5mm
Compression Ratio	13.1:1
Fuel Delivery	Fuel Injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Final Drive	Chain
Rear Brakes	220mm disc; single-piston caliper
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Length	80.3 in
Width	27.8 in
Height	43.1 in
Seat Height	33.5 in
Wheelbase	54.1 in
Fuel Capacity	4.5 gal
Wet Weight	417 lb
Engine Type	Liquid-cooled, inline 4-cylinder, DOHC, 16 valves
Transmission	6-speed
Front Suspension	41 mm inverted fork; 4.7-in travel
Rear Suspension	Single shock; 4.7-in travel
Front Brakes	Dual 310mm disc; radial-mount 4-piston calipers
