Yamaha 2010 YZF-R6 User Manual

– 13 –
12. AIS Plug Set (13S-A4890-70)
This plug set is used when the AIS (Air Induction System), an exhaust gas purification system,
is removed.
Installation
1. Remove the hose attached to the cylinder head cover and the air cut-off valve assembly
accompanying the hose.
2. Remove the cap fitted to the hose and remove the reed valve and plate from the inside.
3. Install the plate (5SL-1482L-70) in replacement of the cap. Apply liquid gasket to the plate.
4. Remove the cylinder head cover and the four collars fitted to the cover. Install the PIN
(93608-16M16).
5. After removing the hose connected to the air cleaner case from the air-cut valve assembly,
open the upper case of the air cleaner case and insert the PLUG (90336-10020) into the
hole where the hose was connected.
Parts List
No. PART No. PART NAME Q'TY REMARKS
1 5SL-1482L-70 PLATE, 2 2
* 2 93608-16M16 PIN, DOWEL 4
3 90336-10020 PLUG, TAPER 1

Yamaha 2010 YZF-R6 Specifications

General

Bore x Stroke	67.0mm x 42.5mm
Compression Ratio	13.1:1
Fuel Delivery	Fuel Injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Final Drive	Chain
Rear Brakes	220mm disc; single-piston caliper
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Length	80.3 in
Width	27.8 in
Height	43.1 in
Seat Height	33.5 in
Wheelbase	54.1 in
Fuel Capacity	4.5 gal
Wet Weight	417 lb
Engine Type	Liquid-cooled, inline 4-cylinder, DOHC, 16 valves
Transmission	6-speed
Front Suspension	41 mm inverted fork; 4.7-in travel
Rear Suspension	Single shock; 4.7-in travel
Front Brakes	Dual 310mm disc; radial-mount 4-piston calipers
