– 1 –
1 Engine Specifications
Spec SSP STK STD
Displacement 599 cm³ 599 cm³ 599 cm³
Bore/Storke 67.0 x 42.5 mm 67.0 x 42.5 mm 67.0 x 42.5 mm
Maximum engine speed
(limiter controlled speed)
15800 rpm 15800 rpm 15800 rpm
Compression ratio
(recommended value)
14.5:1
(Depend of
head-gasket
thickness and
cylinder head
surface
grinding)
13.7:1
(Depending on
the thickness
of the head
gasket)
13.2:1
Valve timing (event angle) INT. 110° 105° 105°
EXT. 115° 110° 110°
Squish height (minimum) 0.60 mm 0.60 mm 0.70 mm
Clearance between valve and
piston (minimum)
INT. 1.05 mm
(ATDC 12°)
1.05 mm
(ATDC 12°)
1.15 mm
(ATDC 12°)
EXT. 1.62 mm
(BTDC 12°)
1.62 mm
(BTDC 12°)
1.80 mm
(BTDC 12°)
valve (tappet) clearance INT. 0.15 – 0.19 mm 0.18 – 0.22 mm 0.18 – 0.22 mm
EXT. 0.23 – 0.27 mm 0.23 – 0.27 mm 0.23 – 0.27 mm

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yamaha 2010 YZF-R6 and is the answer not in the manual?

Yamaha 2010 YZF-R6 Specifications

General IconGeneral
Bore x Stroke67.0mm x 42.5mm
Compression Ratio13.1:1
Fuel DeliveryFuel Injection with YCC-T and YCC-I
IgnitionTCI: Transistor Controlled Ignition
Final DriveChain
Rear Brakes220mm disc; single-piston caliper
Front Tire120/70-ZR17
Rear Tire180/55-ZR17
Length80.3 in
Width27.8 in
Height43.1 in
Seat Height33.5 in
Wheelbase54.1 in
Fuel Capacity4.5 gal
Wet Weight417 lb
Engine TypeLiquid-cooled, inline 4-cylinder, DOHC, 16 valves
Transmission6-speed
Front Suspension41 mm inverted fork; 4.7-in travel
Rear SuspensionSingle shock; 4.7-in travel
Front BrakesDual 310mm disc; radial-mount 4-piston calipers
