Yamaha 2010 YZF-R6 - Chassis Protector Set (2 C0-C117 G-70)

– 40 –
25. Chassis Protector Set (2C0-C117G-70)
Parts List
No. PART No. PART NAME Q'TY REMARKS
1 2C0-2117G-70 PROTECTOR(LH LONG) 1
2 2C0-2117G-90 PROTECTOR(RH SHORT) 1
3 2C0-21472-70 COLLAR, PROTECTOR 2
* 4 91317-10060 BOLT, HEX. SOCKET HEAD 1
5 91314-10065 BOLT, HEX. SOCKET HEAD 1
* 6 90201-10136 WASHER, PLAIN 2
Tightening torque
40 N•m (4.0 m•kg)
Tightening torque
40 N•m (4.0 m•kg)
Tightening torque
FWD
ENGINE
