Yamaha 2010 YZF-R6 User Manual

– 20 –
16. Transmission Gear
Parts List
No. PART No. PART NAME Q'TY REMARKS
1 2C0-17411-80-A AXLE, MAIN 1 A
1 2C0-17411-90-B AXLE, MAIN 1 B
* 1 2C0-17411-00 AXLE, MAIN 1 C
* 2 2C0-15163-00 HSG., BEARING 1
* 3 93306-20562 BRG. 1
4 2C0-17151-71-A GEAR, 5TH PINION 1 A
4 2C0-17151-80-B GEAR, 5TH PINION 1 B
4 2C0-17151-90-C GEAR, 5TH PINION 1 C
5 2C0-17131-80-A GEAR, 3RD PINION 1 A
5 2C0-17131-71-B GEAR, 3RD PINION 1 B
5 2C0-17131-90-C GEAR, 3RD PINION 1 C
6 2C0-17161-70-A GEAR, 6TH PINION 1 A
* 6 2C0-17161-00 GEAR, 6TH PINION 1 B
6 2C0-17161-90-C GEAR, 6TH PINION 1 C
7 2C0-17121-80-A GEAR, 2ND PINION 1 A
7 2C0-17121-90-B GEAR, 2ND PINION 1 B
* 7 2C0-17121-00 GEAR, 2ND PINION 1 C
8 2C0-17402-70 DRIVE, AXLE ASSY. 1
* 9 2C0-17421-00 AXLE, DRIVE 1
* 10 93305-20509 BRG. 1
* 11 90387-25016 COLLAR 1
12 2C0-17221-81-A GEAR, 2ND WHEEL 1 A
12 2C0-17221-90-B GEAR, 2ND WHEEL 1 B
* 12 2C0-17221-00 GEAR, 2ND WHEEL 1 C
13 2C0-17261-71-A GEAR, 6TH WHEEL 1 A
13 2C0-17261-80-B GEAR, 6TH WHEEL 1 B
13 2C0-17261-90-C GEAR, 6TH WHEEL 1 C
14 2C0-17241-80-A GEAR, 4TH WHEEL 1 A
14 2C0-17241-70-B GEAR, 4TH WHEEL 1 B
14 2C0-17241-90-C GEAR, 4TH WHEEL 1 C
15 2C0-17231-80-A GEAR, 3RD WHEEL 1 A
15 2C0-17231-70-B GEAR, 3RD WHEEL 1 B
15 2C0-17231-90-C GEAR, 3RD WHEEL 1 C
16 2C0-17251-71-A GEAR, 5TH WHEEL 1 A
16 2C0-17251-80-B GEAR, 5TH WHEEL 1 B
16 2C0-17251-90-C GEAR, 5TH WHEEL 1 C
17 2C0-17211-80-A GEAR, 1ST WHEEL 1 A
17 2C0-17211-90-B GEAR, 1ST WHEEL 1 B

Yamaha 2010 YZF-R6 Specifications

General

Bore x Stroke	67.0mm x 42.5mm
Compression Ratio	13.1:1
Fuel Delivery	Fuel Injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Final Drive	Chain
Rear Brakes	220mm disc; single-piston caliper
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Length	80.3 in
Width	27.8 in
Height	43.1 in
Seat Height	33.5 in
Wheelbase	54.1 in
Fuel Capacity	4.5 gal
Wet Weight	417 lb
Engine Type	Liquid-cooled, inline 4-cylinder, DOHC, 16 valves
Transmission	6-speed
Front Suspension	41 mm inverted fork; 4.7-in travel
Rear Suspension	Single shock; 4.7-in travel
Front Brakes	Dual 310mm disc; radial-mount 4-piston calipers
