Input/output characteristics
386 PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section
❏ Digital Input Characteristics (PM5D, PM5D-RH)
❏ Digital Input Characteristics (DSP5D)
*1. CASCADE (D-Sub 68pin) Max. Cable length: 200 m@48 kHz, 50 m@96 kHz
*2. CASCADE (RJ-45) Max. Cable length is based on EtherSound standard.
❏ Digital Output Characteristics (PM5D, PM5D-RH)
*1. The channel status of 2TR OUT DIGITAL 1,2 is described on page 387.
*2. The channel status of 2TR OUT DIGITAL 3 is described on page 387.
*3. Dither: word length 16/20/24 bit
*4. XLR-3-32 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
Terminal Format Data Length Level Connector
2TR IN DIGITAL
1 AES/EBU AES/EBU 24bit RS422
XLR-3-31 Type (Balanced)
*1
*1. XLR-3-31 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
2 AES/EBU AES/EBU 24bit RS422
XLR-3-31 Type (Balanced)
*1
3 COAXIAL IEC-60958 24bit 0.5Vpp/75Ω RCA Pin Jack
CASCADE IN — RS422 D-Sub Half Pitch Connector 68P (Female)
Terminal Format Data Length Level Connector
CASCADE IN
*1
——RS422 D-Sub Half Pitch Connector 68P (Female)
CASCADE IN
*2
——100Base-TX RJ-45
Terminal Format Data Length Level Connector
2TR OUT DIGITAL
1 AES/EBU
AES/EBU
*1
Professional Use
24bit
*3
RS422
XLR-3-32 Type (Balanced)
*4
2 AES/EBU
AES/EBU
*1
Professional Use
24bit
*3
RS422
XLR-3-32 Type (Balanced)
*4
3 COAXIAL
IEC-60958
*2
Consumer Use
24bit
*3
0.5Vpp/75Ω RCA Pin Jack
CASCADE OUT — RS422 D-Sub Half Pitch Connector 68P (Female)
