Yamaha PSR-E423 - Panel Controls and Terminals (Rear Panel)

Panel Controls and Terminals
Owner’s Manual
13
Setting Up
!8 [SONG] button ......................................page 30
!9 [STYLE] button .....................................page 26
@0 [MUSIC DATABASE] button.................page 40
@1 [VOICE] button .....................................page 16
@2 Number buttons [0]–[9],
[+] and [-] buttons ................................page 14
@3 [PORTABLE GRAND] button...............page 17
@4 REGIST MEMORY
[MEMORY/BANK], [1], [2] buttons ......page 48
@5 VOICE CONTROL
[SPLIT] button........................... pages 18, 56
[DUAL] button ........................... pages 18, 56
[HARMONY] button ..........................page 57
[TOUCH] button ................................page 56
@6 PITCH BEND wheel..............................page 54
@7 Drum Kit................................................page 16
The illustrations next to each key indicate the drum and per-
cussion instruments assigned to the keys when “Standard Kit
1” is selected.
Rear Panel
@8 USB terminal ........................................ page 73
@9 SUSTAIN jack ....................................... page 11
#0 PHONES/OUTPUT jack........................ page 11
#1 DC IN jack............................................. page 10
@5
!8
@0
@1
@2
@3
@4
!6
!7
@8 @9
#0 #1
!9
Rear Panel
Music Database List
(Data List)
Voice List (Data List)
