Owner’s Manual
86
Reference
Specifications
Keyboards
• 61 standard-size keys (C1–C6), with Touch Response.
Display
• LCD display (backlit)
Setup
•STANDBY/ON
• MASTER VOLUME: MIN–MAX
Realtime Control
• Pitch Bend Wheel
• Knobs A, B
A: Cutoff, Reverb, Attack, Style Cutoff, Style Tempo
B: Resonance, Chorus, Release, Style Resonance
Voice
• 183 panel voices + 15 drum/SFX kits + 462 XGlite voices + 40
arpeggio voices
• Polyphony: 32
• DUAL
•SPLIT
Style
• 174 Preset Styles + External files
• Style Control: ACMP ON/OFF, SYNC STOP,
SYNC START, START/STOP, INTRO/
ENDING/rit., MAIN/AUTO FILL
• Fingering: Multi Finger
• Style Volume
Music Database
•305
Education Feature
• Dictionary
• Lesson 1–3, Repeat & Learn
Registration Memory
• 8 banks x 2 types
Function
• VOLUME: Style Volume, Song Volume
• OVERALL: Tuning, Transpose, Split Point, Touch Sen-
sitivity, Pitch Bend Range
• MAIN VOICE: Volume, Octave, Pan, Reverb Level, Cho-
rus Level, Attack Time, Release Time, Filter
Cutoff, Filter Resonance
• DUAL VOICE:
Voice, Volume, Octave, Pan, Reverb Level,
Chorus Level, Attack Time, Release Time,
Filter Cutoff, Filter Resonance
• SPLIT VOICE:
Voice, Volume, Octave, Pan, Reverb Level,
Chorus Level, Attack Time, Release Time,
Filter Cutoff, Filter Resonance
• EFFECT: Reverb Type, Chorus Type, Master EQ
Type
• HARMONY: Harmony Type, Harmony Volume
• ARPEGGIO: Arpeggio Type, Arpeggio Velocity, Arpeggio
Quantize, Arpeggio Pedal
• SFF Load: Style File Load
•PC: PC Mode
•MIDI:
Local On/Off, External Clock, Initial Send,
Keyboard Out, Style Out, Song Out
• METRONOME: Time Signature Numerator, Time Signature
Denominator, Metronome Volume
• LESSON: Lesson Track (R), Lesson Track (L), Grade
• DEMO: Demo Group, Demo Play, Demo Cancel
Effects
• Reverb: 9 types
• Chorus: 4 types
• Harmony: 26 types
• Arpeggio: 150 types
Song
• 30 Preset Songs + 5 User Songs + Accessory CD-ROM
Songs (70)
• Song Clear, Track Clear
• Song Volume
• Song Control: REPEAT & LEARN, A-B REPEAT, PAUSE,
REW, FF, START/STOP
Performance assistant technology
Recording
•Song
User Song: 5 Songs
Recording Tracks: 1, 2, 3, 4, 5, STYLE
MIDI
• Local On/Off • Initial Send • External Clock
• Keyboard Out • Style Out • Song Out
Auxiliary jacks
• PHONES/OUTPUT, DC IN, USB, SUSTAIN
Amplifier
• 2.5W + 2.5W
Speakers
• 12cm x 2 + 3cm x 2
Power Consumption
• 7W (PA-130)
•10W (PA-3C)
Power Supply
• Adaptor: Users within U.S.: PA-130 or an equivalent
Others: PA-3C, PA-130 or an equivalent
• Batteries: Six “AA” size, LR6 or equivalent batteries
Dimensions (W x D x H)
• 946 x 402 x 136 mm (37-1/4" x 15-13/16" x 5-3/8")
Weight
• 7.0kg (15 lbs. 7 oz.) (not including batteries)
Supplied Accessories
•Music Rest
• Accessory CD-ROM
• Owner’s Manual
• Data List
• My Yamaha Product User Registration
* The PRODUCT ID on the sheet will be needed when you fill out
the User Registration form.
Optional Accessories
• AC Power Adaptor:
Users within U.S.: PA-130 or an equivalent
Others: PA-3C, PA-130 or an equivalent
• Footswitch: FC4/FC5
• Keyboard Stand: L-2C/L-2L
• Headphones: HPE-150/30
* Specifications and descriptions in this owner’s manual are for
information purposes only. Yamaha Corp. reserves the right to change
or modify products or specifications at any time without prior notice.
Since specifications, equipment or options may not be the same in
every locale, please check with your Yamaha dealer.
Appendix
