Yamaha TMAX TECH MAX User Manual

Smart key system
3-6
3
EAU79071
Replacing the smart key bat-
tery
Replace the battery in the following sit-
uations.
 The smart key system indicator
light flashes for about 20 seconds
when the power of the vehicle is
turned on.
 When the smart key indicator light
does not come on when the
“ON/OFF” switch is pushed.
WARNING
EWA20630
The smart key contains a button cell
battery.
 Keep new and used batteries
away from children.
 If the battery compartment does
not close securely, stop using
the smart key and keep it away
from children.
Explosion Hazard - do not mishan-
dle the battery.
 Danger of explosion if battery is
incorrectly replaced.
 Replace only with the same or
equivalent type.
 Do not expose smart key to ex-
cessive heat, such as sunshine
or fire.
Chemical Burn Hazard - do not in-
gest the battery.
 If the battery is swallowed, it
can cause severe internal burns
in just 2 hours and can lead to
death.
 If you think batteries might have
been swallowed or placed in-
side any part of the body, seek
immediate medical
attention.
NOTICE
ECA24010
 Do not apply excessive force to
the smart key when replacing
the battery.
 Do not use a screwdriver or oth-
er hard object to force open the
key.
 Take precautions to prevent the
waterproof seal from being
damaged or contaminated by
dirt.
 Do not touch the internal cir-
cuits and terminals. This may
cause malfunctions.
 Make sure the battery is in-
stalled correctly. Confirm the di-
rection of the positive/“+” side
of the battery.
To replace the smart key battery
1. Gently pry open the smart key
case.
1. Smart key system indicator light “ ”
11
UB3TE0E0.book Page 6 Tuesday, September 17, 2019 9:35 AM

Yamaha TMAX TECH MAX Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Transmission	V-Belt Automatic
Front Suspension	Telescopic forks
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	220 kg
Fuel Tank Capacity	15 litres
Lubrication System	Wet sump
Ignition System	TCI
Starter System	Electric
Front Suspension Travel	120 mm
Rear Suspension Travel	117 mm
Minimum Ground Clearance	135 mm
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Tyre	120/70R15
Rear Tyre	160/60R15
Overall Height	1, 420 mm - 1, 555 mm (adjustable windscreen)
