Yamaha TMAX TECH MAX User Manual

Instrument and control functions
5-14
5
2. Push the “MENU” switch, and
then use the select switch to se-
lect the item to reset.
3. Push the “MENU” switch, and af-
ter the selected item is highlight-
ed, push the select switch “ ”
for one second.
4. When you finished resetting, use
the select switch to highlight “ ”,
and then push the “MENU” switch
to return to the menu screen.
Selecting the units
TIP
U.K. specification vehicles only: This
function does not indicate on setting
mode display and cannot be selected.
1. Use the select switch to highlight
“Unit”.
2. Push the “MENU” switch. The unit
setting display will be shown.
3. Use the select switch to select
“L/100km” or “km/L”.
UB3TE0E0.book Page 14 Tuesday, September 17, 2019 9:35 AM

Yamaha TMAX TECH MAX Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Displacement	562cc
Bore x Stroke	70.0 mm x 73.0 mm
Compression Ratio	10.9:1
Fuel System	Fuel Injection
Transmission	V-Belt Automatic
Front Suspension	Telescopic forks
Rear Suspension	Swingarm
Front Brake	Hydraulic dual disc, Ø267 mm
Rear Brake	Hydraulic single disc, Ø282 mm
Overall Length	2, 200 mm
Overall Width	765 mm
Seat Height	800 mm
Wheelbase	1, 575 mm
Wet Weight	220 kg
Fuel Tank Capacity	15 litres
Lubrication System	Wet sump
Ignition System	TCI
Starter System	Electric
Front Suspension Travel	120 mm
Rear Suspension Travel	117 mm
Minimum Ground Clearance	135 mm
Maximum Torque	55.7 Nm @ 5, 250 rpm
Front Tyre	120/70R15
Rear Tyre	160/60R15
Overall Height	1, 420 mm - 1, 555 mm (adjustable windscreen)
