STARTER MOTOR
BY Service Manual
10-5
Introduction
INTRODUCTION
This section of the Service Manual covers servicing of starter motor on 4BY and 6BY engines.
STARTER MOTOR SPECIFICATIONS
General Specifications
Special Torque Chart
Item Bosch (4BY) Denso (6BY)
Nominal Power 2.0 kW 2.0 kW
Nominal Voltage 12V 12V
Test Voltage 13 ± 0.26V 13 ± 0.26V
Maximum Operating Temperature 120°C (248°F) 120°C (248°F)
Rotation Clockwise Clockwise
Weight 3.5 kg (7.7 lb) 3.5 kg (7.7 lb)
Item Specification
Battery Positive (+) Cable 15 N·m (133 in.-lb)
Solenoid Primary Wire 8 N·m (71 in.-lb)
