Yanmar 4BY - Page 64

ENGINE
BY Service Manual
5-9
Specifications
Crankshaft
and Main
Bearings
Standard Yellow
59.977 - 59.983 mm
(2.3613 - 2.3615 in.)
Standard Green
59.970 - 59.976 mm
(2.3610 - 2.3613 in.)
Standard White
59.964 - 59.969 mm
(2.3608 - 2.3610 in.)
Undersize 1 (U 0.25) Yellow
59.727 - 59.733 mm
(2.3514 - 2.3517 in.)
Undersize 1 (U 0.25) Green
59.720 - 59.726 mm
(2.3512 - 2.3514 in.)
Undersize 1 (U 0.25) White
59.714 - 59.719 mm
(2.3509 - 2.3511 in.)
Undersize 2 (U 0.50) Yellow
59.477 - 59.483 mm
(2.3416 - 2.3418 in.)
Undersize 2 (U 0.50) Green
59.470 - 59.476 mm
(2.3413 - 2.3416 in.)
Undersize 2 (U 0.50) White
59.464 - 59.469 mm
(2.3411 - 2.3413 in.)
Crankshaft Bearing Clearance, Radial
0.019 - 0.052 mm
(0.0007 - 0.0020 in.)
Crankshaft
Thrust
Bearings
Standard
25.00 +0.020 / +0.066 mm
(0.9842 +0.0008 / +0.0026 in.)
Size 1
25.2 +0.020 / +0.066 mm
(0.9921 +0.0008 / +0.0026 in.)
Size 2
25.4 +0.020 / +0.066 mm
(1.000 +0.0008 / +0.0026 in.)
Crankshaft Axial Play
0.06 - 0.25 mm
(0.0024 - 0.0098 in.)
Connecting
Rod Journals
Standard
45.00 -0.009 / -0.025 mm
(1.7716 -0.0004 / -0.0010 in.)
Size 1
44.75 -0.009 / -0.025 mm
(1.7618 -0.0004 / -0.0010 in.)
Size 2
44.50 -0.009 / -0.025 mm
(1.7520 -0.0004 / -0.0010 in.)
Radial Bearing Play
0.015 - 0.050 mm
(0.0006 - 0.0020 in.)
Engine
Vibration
Damper
Maximum Permitted Radial Runout
0.40 mm
(0.016 in.)
Maximum Permitted Axial Runout
0.40 mm
(0.016 in.)
Component Remarks Specification
