(12) Remove the following parts from the power
steering valve.
(A) Pipe from the hydraulic pump (High pressure)
(B) Return pipe (Low pressure)
IMPORTANT
When the clutch housing section is separated
without removing the pipes (A) and (B), the
pipes could get caught in the starter and be
destroyed.
When removing the pipes (A) and (B),
remember the position they were in, in order to
reassemble them correctly.
