Permanent Installation Examples cont.
Anchoring Hardware not included
Anchoring Hardware not included
Anchoring Hardware (not included)
Post
Mount
Post Mounts have a 1.27 cm (1/2”) diameter hole
for anchoring hardware.
Concrete Patio [min. 3.616 m x 4.226 m (11’10-3/8” x 13’10-3/8”)]
with 15.24 cm (6”) clearance on all sides
Wood Deck [min. 3.616 m x 4.226 m (11’10-3/8” x 13’10-3/8”)]
with 15.24 cm (6”)clearance on all sides
Post
Mount
