Yardistry YM12978 User Manual

9 support@yardistrystructures.com
Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
2pc. (337) -
Strap Short 1561.3mm
(61 1/2")
Y50229-337
2pc. (430) -
Strap Short - Large Roof 2170.9mm
(85 1/2")
Y50229-430
2pc. (432) -
Strap Right - Large Roof 1605.6mm
(63 3/16")
Y50229-432
2pc. (437) -
Strap 2603.5mm
(102 1/2")
Y50229-437
2pc. (433) -
Strap Brace 574.7mm
(22 5/8")
Y50229-433
2pc. (431) -
Strap Left - Large Roof 1605.6mm
(63 3/16")
Y50229-431
2pc. (461) -
Tie 2336.8mm
(92")
Y50229-461
4pc. (1049) -
Arched Gusset 1117.6mm
(44")
Y70229-1049
1pc. (463) -
Spacer Top 574.7mm
(22 5/8")
Y50229-463
4pc. (1053) -
Arched Gusset Short 1066.8mm
(42")
Y70229-1053
