4 Option Components
16 YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual
■ Connecting the Option to D1000
Table 8 LED Status and Meaning
Figure 5
Figure 5 RUN LED Status
Figure 6
Figure 6 RUN LED and Converter Operation
LED Illuminated Flashing Quickly <1> Off
<1> Refer to Figure 5 for the difference between “flashing” and “flashing quickly”.
When the run command is
selected from the LED
operator (LOCAL).
–
When a device other than the
option is selected for Run
command and frequency reference
control (REMOTE).
During run.
During stop by External Fault
digital input.
During stop.
Examples
RE
LO
RUN
Flashing
quickly
Flashing
ON ON
ON
ON ON
ON
1 s
/
RUN STOP
RUN LED OFF OFFON
DC bus voltage reference
DC bus voltage
STOP
RUN
