YASKAWA 1000 Series

4 Option Components
20 YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual
8
Function Key 1
(F1)
JOG
<1>
Pressing executes the Jog function.
HELP
Pressing displays the Help menu.
←
Pressing scrolls the cursor to the left.
HOME
Pressing will return to the following display:
Drive: Frequency Reference
Converter: DC Bus Voltage Reference
Regenerative unit: DC Bus Voltage
ESC
Pressing returns to the previous display.
9
FWD/REV
<1>
FWD Indicates forward motor operation.
REV Indicates reverse motor operation.
10
Function Key 2
(F2)
FWD/REV
<1>
Pressing switches between forward and reverse.
DATA
Pressing scrolls to the next display.
→
Pressing scrolls the cursor to the right.
RESET
Pressing resets the existing unit fault or error.
<1> Not available for the converter and regenerative unit.
<2> Displayed when in Frequency Reference, Voltage Reference, or Run Command Mode.
<3> Displayed when in Frequency Reference, Voltage Reference, or Run Command Mode and Monitor Mode.
No. Name Display Content
F1
F1
F1
F1
F1
F2
F2
F2
F2
