YASKAWA 1000 Series Installation Manual

4 Option Components
YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual 19
6
Drive:
Frequency
Reference
Assignment
<2>
OPR Displayed when the frequency reference is assigned to the option.
AI
Displayed when the frequency reference is assigned to the Analog Input of
the drive.
COM
Displayed when the frequency reference is assigned to the MEMOBUS/
Modbus Communication Inputs of the drive.
OP
Displayed when the frequency reference is assigned to an Option Unit of the
drive.
RP
Displayed when the frequency reference is assigned to the Pulse Train Input
of the drive.
Converter:
Voltage Reference
Assignment
<2>
OPR Displayed when the voltage reference is assigned to the option.
AI
Displayed when the voltage reference is assigned to the Analog Input of the
converter.
COM
Displayed when the voltage reference is assigned to the MEMOBUS/
Modbus Communication Inputs of the converter.
OP
Displayed when the voltage reference is assigned to an Option Unit of the
converter.
AUTO
Displayed when b1-18 is set to either 7 or 8 (input voltage based control 1 or
2).
Regenerative Unit:
Run Command
Assignment
<2>
OPR Displayed when the Run command is assigned to the option.
AI
Displayed when the Run command is assigned to the Analog Input of the
regenerative unit.
COM
Displayed when the Run command is assigned to the MEMOBUS/Modbus
Communication Inputs of the regenerative unit.
OP
Displayed when the Run command is assigned to an Option Unit connected
to the regenerative unit.
7
LO/RE
Display
<3>
RSEQ Displayed when the Run command is supplied from a remote source.
LSEQ Displayed when the Run command is supplied from the digital operator.
RREF
Drive: Displayed when the frequency reference is supplied from a remote
source.
Converter: Displayed when the voltage reference is supplied from a remote
source.
Regenerative unit: Displayed when the Run command is supplied from a
remote source.
LREF
Drive: Displayed when the frequency reference is supplied from the digital
operator.
Converter: Displayed when the voltage reference is supplied from the digital
operator.
Regenerative unit: Displayed when the Run command is supplied from the
digital operator.
No. Name Display Content
