6 Basic Operation
YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual 29
■ Example: Basic Operation
The following procedures are examples of drive operation using the option.
Note: Actual LCD display data varies based on drive parameter settings.
Procedure Example: RUN/STOP
Note: If b1-01 is not set to 0 (Operator), press to set LOCAL.
Procedure LCD Display
1. Apply main power to the drive. The Frequency Reference appears after the initial
display on the option.
2. Press to show the display for inputting the frequency reference.
If b1-01 is not set to 0 (Operator), press to set LOCAL.
3. Press until the frequency
reference changes to 006.00 Hz.
4. Press to set the output frequency.
RE
LO
- MODE -
U1-01= 0.00Hz
U1-02= 0.00Hz
U1-03= 0.00A
DRV
FREF (OPR)
Rdy
JOG FWD FWD/REV
LSEQ
LREF
RE
LO
←→
-MONITR-
FREF (d1-01)
U1-01= 000.00Hz
㧔0.00㨪60.00㧕
0.00Hz
DRV
FWD
Rdy
F1 F2
←→
-MONITR-
FREF (d1-01)
U1-01= 006.00Hz
㧔0.00㨪60.00㧕
0.00Hz
DRV
FWD
Rdy
Entry Accepted
